GMC-2CUPXD
Callisto 2 Channel 3G SDI UPXD
THIS IS A SOFTWARE LICENSE – GREEN MACHINE CALLISTO HARDWARE REQUIRED
The greenMachine 2CUPXD license pack (constellation) is a broadcast-quality 2-Channel Up/Down/Cross converter with a frame synchronizer supporting two independent 3G-SDI inputs up to 1920x1080p 60. It includes full audio processing capabilities, scalars for the spatial conversion of the video signals including a versatile region of interest (ROI) selection and high-performance deinterlacers on the two processing channels.
Color correction:
Adjust saturation, gain, offset, lift, gamma, hue, blanking interval deletion and aperture correction.
Apply horizontal flip and YCbCr headroom clipping.
Audio:
Multi-format audio embedder and de-embedder on all channels present on the video source.
Gain adjustment, 1kHz test tone, mute, inversion, mono mix-down, silence and overload monitoring
2x Dolby E® decoder for all 8 channels in a stream
Dolby® metadata can be mapped to VANC acc. to SMPTE 2020-3 and SMPTE 2020-2.
The greenMachine 2CUPXD license pack comes with a fully-featured local control interface for the mini LCD display allowing image previews and audio level meters of the processed video streams. It is fully compatible with Lynx Centraal for remote control, status monitoring and error reporting.
Key Features
• Two independent 3G channels (2x3G)
• Spatial converter with a powerful region of interest (ROI) selection and scaling.
• Deinterlacers with Motion adaptive filtering on channel 1 and channel 2
• Automatic detection of 3G level A/B
• Automatically match the video processing delay with embedded audio
• Adjust saturation, black gain and hue, blanking interval deletion, aperture correction and much more
• Adjust gain, offset, lift, and gamma for RGB and CMYK.
• Multi-format audio embedder and de-embedder
• Provides audio gain adjustment, mute, inversion, stereo to mono-mix and much more
• Two Dolby E® decoders can be used to decode all 8 channels contained in a Dolby E® stream.
• The Dolby® metadata can be mapped to VANC acc. to SMPTE 2020-3 and SMPTE 2020-2.
• Full MADI in/out support if the greenMachine is equipped with an optionally available MADI SFP.
• Each video and AES or MADI audio channel can be individually delayed
Refer to Datasheet
